Brand

FIELDPIECE

AC Response Calculation

TRMS

Instrument Safety Rating

CAT III 600V

Calibration Certificate Included

No

Instrument Counts

1,999

Parameters Measured

• AC Voltage
• DC Voltage
• Capacitance
• Continuity
• Diode
• Resistance
• Temperature

Basic AC Voltage Accuracy

±1.20% Reading + 3 Digit; ± 2% Reading + 5 Digit (on 600 V)

Basic DC Voltage Accuracy

±0.50% Reading + 1 Digit

Battery Access

Yes

Battery Chemistry

Alkaline

Battery Size

9V

Capacitance Measurement Accuracy

±3% Reading + 5 Digit

Capacitance Measurement Resolution

0.1 uF

DC Voltage Measurement Resolution

0.1 mV

Diode Test

Yes

Maximum Capacitance Measurement

200 uF

Maximum Operating Temperature

122 °F

Maximum Resistance Measurement

200 kiloohm

Maximum Storage Temperature

140 °F

Minimum Operating Temperature

32 °F

Minimum Storage Temperature

-4 °F

Resistance Measurement Accuracy

±1% Reading + 4 Digit

Resistance Measurement Resolution

0.1 ohm

Special Features

Auto Power Off - 60 Minutes

Standards

CE; IEC 61010-1 (EN61010-1); UL; UL 3111

Temperature Measurement Accuracy

±1% + 1.5°F; ±1°F; ±2% + 3°F (-30 to -4°F)

Manufacturers Warranty Length

1 yr

Maximum Temperature Measurement

200 °F

Minimum Temperature Measurement

-30 °F
